Precision Insert Parts and Brass Threaded Inserts

Real brass threaded insert examples with drawing-defined threads, knurled geometry, mating interfaces and acceptance scope.

Precision Insert Parts and Brass Threaded Inserts

Zhengna Technology supports drawing-led enquiries for precision insert parts. The brass threaded inserts shown below are real supplied product examples with internal threads, straight knurled bands at both ends and a reduced smooth center section. Use the photograph to identify the component form, then use a controlled drawing to define the part to be quoted.

Real brass knurled insert examples

Two brass threaded inserts with internal threads, knurled end bands and reduced center sections

The material family is brass; the exact alloy and temper are not specified for these examples. The photograph does not establish thread size or class, dimensions, coating, installation method or tested retention. In particular, a knurled exterior alone is not approval for heat, ultrasonic, press-in or molded-in installation.

Define the insert separately from the assembly

For the loose insert, identify the internal thread system, size, pitch, tolerance or class, usable thread length and entry condition. Dimension the knurled outside bands, their length and position, the reduced center, overall length and any end-face requirements. State the material designation and final surface condition rather than selecting either from the image.

The mating component needs its own definition. Provide its material, hole drawing, installation direction and intended seated position. If installation is outside the ordered supply scope, name the party responsible for that operation and for approving the assembled joint. A dimensional inspection of the metal insert does not establish assembly strength.

Quotation and acceptance scope

  • Send the controlling drawing and revision, with a model or sample when available.
  • Mark the thread and external features that require acceptance evidence, including the condition before or after any specified finish.
  • Separate loose-part dimensional and thread checks from installation, torque-out, pull-out or other assembly validation.
  • State quantities, delivery destination, packaging and thread-protection needs. MOQ, price, lead time and documentation are reviewed for the particular order; none are established by these examples.

The manufacturing route and any secondary operations require project-specific review. This page does not identify which operations produced the photographed examples or promise that every operation is performed in-house.

Before releasing the mating component, use the insert, mating-hole and installation acceptance review. It distinguishes a thread check on the loose part from acceptance of the installed joint.

For the wider machining scope, see custom CNC machining parts and Swiss machining parts. Use Contact Zhengna Technology to describe the project and agree the drawing, supply and evidence requirements.
